Characterized frequency range: 60 kHz – 500 MHz
Directivity:
60 kHz – 500 MHz > 20 dB
150 kHz – 300 MHz > 25 dB
200 kHz – 30 MHz > 30 dB
Coupling:
60 kHz – 100 MHz -50 dB ± 0.7 dB,
100 MHz – 500 MHz -50 dB + 0.7/- 10 dB
Insertion loss:
60 kHz – 200 MHz < 0.15 dB
200 MHz – 500 MHz < 0.6 dB
Max. power:
60 kHz – 200 MHz 200 W CW *)
200 MHz – 500 MHz 100 W CW *)
*) Short time (max. 1 minute): 350 W Output shorted or open: max. 80 W
Operating temperature range: - 20 °C to + 40 °C
Impedance: 50 Ω
Port matching: > 20 dB
RF connectors, through ports: N-female
RF connectors, coupling ports: SMA-female
Dimensions: 113 mm x 60 mm x 35 mm
Weight: 290 g
