Product image

Tektronix AFG3022C Arbitrary Function Generators (25 MHz, 2CH, 250MS/s)

ManufacturerTEKTRONIX(View more products from this manufacturer)

ModelAFG3022C

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Channels: 2
Waveforms: Sine, Square, Pulse, Ramp, Triangle, Sin(x)/x, Exponential Rise and Decay, Gaussian, Lorentz, Haversine, DC, Noise
Sample Rate: 2 to 128K:250MS/s
Sine Wave: 1 µHz to 25 MHz
Square Wave: 1 µHz to 25 MHz
Ramp Wave: 1 µHz to 500 kHz
Pulse Wave: 1 mHz to 25 MHz
Other Waveforms: 1 µHz to 500 kHz
Arbitrary Waveforms: 1 mHz to 12.5 MHz
Amplitude Range (50Ω load): 10 mVp-p to 10 Vp-p
Range (open circuit or High Z): 20 mVp-p to 20 Vp-p
Modulation: AM, FM, PM, FSK, PWM
Display: 5.6 in. Color TFT LCD
Power Source: 100-240 V, 47-63 Hz
Power Consumption: Less than 120 W
Dimensions: 156.3 x 329.6 x 168.0 mm
Weight: 4.5 kg
Includes: Quick-start user manual, power cord, USB cable, CD-ROM with specifications and performance verification manual, programmer manual, service manual, LabView and IVI drivers, CD-ROM with ArbExpress™ software, and NIST-traceable calibration certificate. Please specify power plug when ordering.

Option:
Rackmount Kit: RM3100
Fuse adapter, BNC-P to BNC-R: 013-0345-xx
Fuse set, 3 pcs, 0.125 A: 159-0454-xx
BNC cable shielded, 3 ft: 012-0482-xx
BNC cable shielded, 9 ft: 012-1256-xx
GPIB cable, double shielded: 012-0991-xx
50 O BNC terminator: 011-0049-02

Characteristics

AFG3000C Series Characteristics

Characteristic	AFG3011C	AFG3021C AFG3022C	AFG3051C AFG3052C	AFG3101C AFG3102C	AFG3251C AFG3252C
Channels	1	1 / 2	1 / 2	1 / 2	1 / 2
Waveforms	Sine, Square, Pulse, Ramp, Triangle, Sin(x)/x, Exponential Rise and Decay, Gaussian, Lorentz, Haversine, DC, Noise
Sine Wave	1 µHz to 10 MHz	1 µHz to 25 MHz	1 µHz to 50 MHz	1 µHz to 100 MHz	1 µHz to 240 MHz
Sine wave in Burst Mode	1 µHz to 5 MHz	1 µHz to 12.5 MHz	1 µHz to 25 MHz	1 µHz to 50 MHz	1 µHz to 120 MHz
Effective maximum frequency out	10 MHz	25 MHz	50 MHz	100 MHz	240 MHz
Amplitude Flatness (1 V_p-p)	<5 mhz:="" 0="" 15="" db="" p=""> ≥5 MHz to 10 MHz: ±0.3 dB	<5 mhz:="" 0="" 15="" db="" p=""> ≥5 MHz to 20 MHz: ±0.3 dB ≥20 MHz to 25 MHz: ±0.5 dB	<5 mhz:="" 0="" 15="" db="" p=""> ≥5 MHz to 45 MHz: ±0.3 dB ≥45 MHz to 50 MHz: ±0.5 dB	<5 mhz:="" 0="" 15="" db="" p=""> ≥5 MHz to 25 MHz: ±0.3 dB ≥25 MHz to 100 MHz: ±0.5 dB	<5 mhz:="" 0="" 15="" db="" p=""> ≥5 MHz to 25 MHz: ±0.3 dB ≥25 MHz to 100 MHz: ±0.5 dB ≥100 MHz to 200 MHz: ±1.0 dB ≥200 MHz to 240 MHz: ±2.0 dB
Harmonic Distortion (1 V_p-p)	10 Hz to 20 kHz: < -60 dBc ≥20 kHz to 1 MHz: < -55 dBc ≥1 MHz to 5 MHz: < -45 dBc ≥5 MHz to 10 MHz: < -45 dBc	10 Hz to 20 kHz: < -70 dBc ≥20 kHz to 1 MHz: < -60 dBc ≥1 MHz to 10 MHz: < -50 dBc ≥10 MHz to 25 MHz: < -40 dBc	10 Hz to 20 kHz: < -70 dBc ≥20 kHz to 1 MHz: < -60 dBc ≥1 MHz to 5 MHz: < -50 dBc ≥5 MHz to 50 MHz: < -40 dBc	10 Hz to 1 MHz: < -60 dBc ≥1 MHz to 5 MHz: < -50 dBc ≥5 MHz to 100 MHz: < -37 dBc	10 Hz to 1 MHz: < -60 dBc ≥1 MHz to 5 MHz: < -50 dBc ≥5 MHz to 25 MHz: < -37 dBc ≥25 MHz to 240 MHz: < -30 dBc
THD	<0.2% (10 Hz – 20 kHz, 1 V_p-p)
Spurious (1 V_p-p)	10 Hz to 1 MHz: < -60 dBc ≥1 MHz to 10 MHz: < -50 dBc	10 Hz to 1 MHz: < -60 dBc ≥1 MHz to 25 MHz: < -50 dBc	10 Hz to 1 MHz: < -60 dBc ≥1 MHz to 50 MHz: < -50 dBc	10 Hz to 1 MHz: < -60 dBc ≥1 MHz to 25 MHz: < -50 dBc ≥25 MHz to 100 MHz: < - 50 dBc + 6 dBc/octave	10 Hz to 1 MHz: < -50 dBc ≥1 MHz to 25 MHz: < -47 dBc ≥25 MHz to 240 MHz: < - 47 dBc + 6 dBc/octave
Phase noise, typical	< -110 dBc/Hz at 10 MHz, 10 kHz offset, 1 V_p-p	< -110 dBc/Hz at 20 MHz, 10 kHz offset, 1 V_p-p
Residual clock noise	-63 dBm	-63 dBm	-63 dBm	-57 dBm	-57 dBm
Square Wave	1 µHz to 5 MHz	1 µHz to 25 MHz	1 μHz to 40 MHz	1 µHz to 50 MHz	1 µHz to 120 MHz
Rise/Fall time	≤50 ns	≤9 ns	≤7 ns	≤5 ns	≤2.5 ns
Jitter (RMS), typical	500 ps	500 ps	300 ps	200 ps	100 ps
Ramp Wave	1 µHz to 100 kHz	1 µHz to 500 kHz	1 μHz to 800 kHz	1 µHz to 1 MHz	1 µHz to 2.4 MHz
Linearity, typical	≤0.2% of peak output	≤0.1% of peak output	≤ 0.1% of peak output	≤0.15% of peak output	≤0.2% of peak output
Symmetry	0.0% to 100.0%
Pulse Wave	1 mHz to 5 MHz	1 mHz to 25 MHz	1 mHz to 40 MHz	1 mHz to 50 MHz	1 mHz to 120 MHz
Pulse width	80.00 ns to 999.99 s	16.00 ns to 999.99 s	12 ns to 999.99 s	8.00 ns to 999.99 s	4.00 ns to 999.99 s
Resolution	10 ps or 5 digits
Pulse duty	0.001% to 99.999% (Limitations of pulse width apply)
Edge transition time	50 ns to 625 s	9 ns to 625 s	7 ns to 625 s	5 ns to 625 s	2.5 ns to 625 s
Resolution	10 ps or 4 digits
Lead delay
Range	(Continuous Mode): 0 ps to Period (Triggered/Gated Burst Mode): 0 ps to Period – [Pulse Width + 0.8 * (Leading Edge Time + Trailing Edge Time)]
Resolution	10 ps or 8 digits
Overshoot, typical	<5%
Jitter (RMS), typical	500 ps	500 ps	300 ps	200 ps	100 ps
Other Waveforms	1 µHz to 100 kHz	1 µHz to 500 kHz	1 μHz to 800 kHz	1 µHz to 1 MHz	1 µHz to 2.4 MHz
Noise Bandwidth (-3 dB)	10 MHz	25 MHz	50 MHz	100 MHz	240 MHz
Noise type	White Gaussian
Internal Noise Add	When activated, output signal amplitude is reduced to 50%
Level	0.0% to 50% of amplitude (V_p-p) setting
Resolution	1%
DC (into 50 Ω)	-10 V to +10 V	-5 V to +5 V	–5 V to +5 V	-5 V to +5 V	-2.5 V to +2.5 V
Arbitrary Waveforms	1 mHz to 5 MHz	1 mHz to 12.5 MHz	1 mHz to 25 MHz	1 mHz to 50 MHz	1 mHz to 120 MHz
Arbitrary waveforms in Burst Mode	1 mHz to 2.5 MHz	1 mHz to 6.25 MHz	1 mHz to 12.5 MHz	1 mHz to 25 MHz	1 mHz to 60 MHz
Effective analog bandwidth (-3 dB)	8 MHz	70 MHz		100 MHz	225 MHz
Nonvolatile memory	4 waveforms
Memory: Sample rate (1K=1024 points)	2 to 128 K: 250 MS/s	2 to 128 K: 250 MS/s	2 to 16 K: 1 GS/s >16 K to 128 K: 250 MS/s	2 to 16 K: 1 GS/s >16 K to 128 K: 250 MS/s	2 to 16 K: 2 GS/s >16 K to 128 K: 250 MS/s
Vertical resolution	14 bits
Rise/Fall time	≤80 ns	≤14 ns	≤10 ns	≤8 ns	≤3 ns
Jitter (RMS), typical	4 ns	4 ns	1 ns at 1 GS/s 4 ns at 250 MS/s	1 ns at 1 GS/s 4 ns at 250 MS/s	500 ps at 2 GS/s 4 ns at 250 MS/s
Amplitude
Range (50 Ω load)	20 mV_p-p to 20 V_p-p	10 mV_p-p to 10 V_p-p	10 mV_p-p to 10 V_p-p	20 mV_p-p to 10 V_p-p	≤200 MHz: 50 mV_p-p to 5 V_p-p >200 MHz: 50 mV_p-p to 4 V_p-p
Range (open circuit or High Z)	40 mV_p-p to 40 V_p-p	20 mV_p-p to 20 V_p-p	20 mV_p-p to 20 V_p-p	40 mV_p-p to 20 V_p-p	≤200 MHz: 100 mV_p-p to 10 V_p-p >200 MHz: 100 mV_p-p to 8 V_p-p
Accuracy	±(2% of setting +2 mV) (1 kHz sine wave, 0 V offset, >20 mV_p-p amplitude)	±(1% of setting +1 mV) (1 kHz sine wave, 0 V offset, >10 mV_p-p amplitude)
Resolution	0.1 mV_p-p, 0.1 mV_RMS, 1 mV, 0.1 dBm or 4 digits
Units	V_p-p, V_RMS, dBm (sine wave only) and Volt (high/low setting)
Output impedance	50 Ω
Load impedance setting	Selectable: 50 Ω, 1Ω to 10.0 kΩ, High Z (Adjusts displayed amplitude according to selected load impedance)
Isolation	<42 v="" sub="">pk maximum to earth
Short-circuit protection	Signal outputs are robust against permanent shorts against floating ground
External voltage protection	To protect signal outputs against external voltages use fuse adapter 013-0345-xx
DC Offset
Range (50 Ω load)	±(10 V_pk – Amplitude_pp/2)	±(5 V_pk – Amplitude_pp/2)	±(5 V_pk – Amplitude_pp/2)	±5 V_pk DC	±2.5 V_pk DC
Range (open circuit or High Z)	±(20 V_pk – Amplitude_pp/2)	±(10 V_pk – Amplitude_pp/2)	±(10 V_pk – Amplitude_pp/2)	±10 V_pk DC	±5 V_pk DC
Accuracy	±(2% of \|setting\| + 10 mV + 1% of amplitude (V_p-p))	±(1% of \|setting\| + 5 mV + 0.5% of amplitude (V_p-p))
Resolution	1 mV

System Characteristics

Characteristic	Description
Frequency Resolution	1 μHz or 12 digits
Internal Frequency Reference
Stability	All except ARB: ±1 ppm, 0 °C to 50 °C ARB: ±1 ppm ± 1 µHz, 0 °C to 50 °C
Aging	±1 ppm per year
Phase (except DC, Noise, Pulse)
Range	-180° to +180°
Resolution	0.01° (sine), 0.1° (other waveforms)
	When activated, output signal amplitude is reduced to 50%
Level	0.0% to 50% of amplitude (V_p-p) setting
Resolution	1%
Main Output	50 Ω
Remote Programming	GPIB, LAN 10BASE-T / 100BASE-TX, USB 1.1 Compatible with SCPI-1999.0 and IEEE 488-2 standards
Configuration times, max typical	USB	LAN	GPIB
Function change	81 ms	81 ms	81 ms
Frequency change (except Pulse)	2.5 ms	6 ms	3.2 ms
Frequency change (Pulse)	40 ms	37 ms	32 ms
Amplitude change	90 ms	97 ms	90 ms
Select user ARB (4k points from USB Memory)	48 ms	50 ms	49 ms
Select user ARB (128k points from USB Memory)	260 ms	266 ms	240 ms
Data download time for 4000 point waveform data, typical	47 ms	78 ms	320 ms
Power Source	100-240 V, 47-63 Hz, or 115 V, 360-440 Hz
Power Consumption	Less than 120 W
Warm-up Time, typical	20 minutes
Power-on Self Diagnostics, typical	<10 s="" p="">
Acoustic Noise, typical	<50 dba="" p="">
Display	5.6 in. Color TFT LCD
User Interface and Help Languages	English, French, German, Japanese, Korean, Portuguese, Simplified and Traditional Chinese, Russian (user selectable)

Modulation

Modulation: Max FM Peak Deviation

Characteristic	AFG3011C	AFG3021C AFG3022C	AFG3051C AFG3052C	AFG3101C AFG3102C	AFG3251C AFG3252C
Sine	5 MHz	12.5 MHz	25 MHz	50 MHz	120 MHz
Square	2.5 MHz	12.5 MHz	20 MHz	25 MHz	60 MHz
ARB	2.5 MHz	6.25 MHz	12.5 MHz	25 MHz	60 MHz
Others	50 kHz	250 kHz	400 kHz	500 kHz	1.2 MHz

AM, FM, PM

Characteristic	Description
Carrier Waveforms	All, except Pulse, Noise, and DC
Source	Internal/External
Internal Modulating Waveform	Sine, square, ramp, noise, ARB (AM: maximum waveform length 4,096; FM/PM: maximum waveform length 2,048)
Internal Modulating Frequency	2 mHz to 50.00 kHz
AM Modulation Depth	0.0% to +120.0%
Min FM Peak Deviation	DC
Max FM Peak Deviation	See following table, Modulation: Max FM Peak Deviation
PM Phase Deviation	-360.0° to +360.0°

Pulse Width Modulation

Characteristic	Description
Carrier Waveform	Pulse
Source	Internal/External
Internal Modulating Waveform	Sine, square, ramp, noise, ARB (maximum waveform length 2,048)
Internal Modulating Frequency	2 mHz to 50.00 kHz
Deviation	0% to 50.0% of pulse period

Sweep: Max Start/Stop Frequency

Characteristic	AFG3011C	AFG3021C AFG3022C	AFG3051C AFG3052C	AFG3101C AFG3102C	AFG3251C AFG3252C
Sine	10 MHz	25 MHz	50 MHz	100 MHz	240 MHz
Square	5 MHz	25 MHz	40 MHz	50 MHz	120 MHz
ARB	5 MHz	12.5 MHz	25 MHz	50 MHz	120 MHz
Others	100 kHz	500 kHz	800 kHz	1 MHz	2.4 MHz

Frequency Shift Keying

Characteristic	Description
Carrier Waveforms	All, except Pulse, Noise, and DC
Source	Internal/External
Internal Modulating Frequency	2 mHz to 1.000 MHz
Number of Keys	2

Sweep

Characteristic	Description
Waveforms	All, except Pulse, Noise, and DC
Type	Linear, logarithmic
Sweep Time	1 ms to 300 s
Hold/Return Time	0 ms to 300 s
Max Total Sweep Time	300 s
Resolution	1 ms or 4 digits
Total Sweep Time Accuracy, typical	≤0.4%
Min Start/Stop Frequency	All except ARB: 1 µHz ARB: 1 mHz
Max Start/Stop Frequency	See chart, below

Burst

Characteristic	Description
Waveforms	All, except Noise and DC
Type	Triggered, gated (1 to 1,000,000 cycles or Infinite)
Internal Trigger Rate	1 μs to 500.0 s
Gate and Trigger Sources	Internal, external, remote interface

Auxiliary Inputs

Characteristic	Description
Modulation Inputs Channel 1, Channel 2
Input range	All except FSK: ±1 V FSK: 3.3 V logic level
Impedance	10 kΩ
Frequency range	DC to 25 kHz (122 kS/s)
External Triggered/Gated Burst Input
Level	TTL compatible
Impedance	10 kΩ
Pulse width	100 ns minimum
Slope	Positive/Negative, selectable
Trigger delay	0.0 ns to 85.000 s
Resolution	100 ps or 5 digits
Jitter (RMS), typical	Burst: <500 ps="" trigger="" input="" to="" signal="" output="" p="">
10 MHz Reference Input
Impedance	1 kΩ, AC coupled
Required Input Voltage Swing	100 mV_p-p to 5 V_p-p
Lock Range	10 MHz ±35 kHz
External Add Input (CH1)	AFG3101C, AFG3102C, AFG3251C, AFG3252C only
Impedance	50 Ω
Input range	-1 V to +1 V (DC + peak AC)
Bandwidth	DC to 10 MHz (-3 dB) at 1 V_p-p

Auxiliary Outputs

Characteristic	Description
Trigger Output (Channel 1)
Level	Positive TTL level pulse into 1 kΩ
Impedance	50 Ω
Jitter (RMS), typical	AFG3011C/21C/22C: 500 ps AFG3051C/52C: 300ps AFG3101C/02C: 200 ps AFG3251C/52C: 100 ps
Max Frequency	4.9 MHz (4.9 MHz to 50 MHz: A fraction of the frequency is output; >50 MHz: no signal is output)
Clock Reference Out (10 MHz)	AFG3101C, AFG3102C, AFG3251C, AFG3252C only
Impedance	50 Ω, AC coupled
Amplitude	1.2 V_p-p into 50 Ω load

Physical Characteristics

Benchtop Configuration

Dimensions	mm	in.
Height	156.3	6.2
Width	329.6	13.0
Depth	168.0	6.6
Weight	kg	lb.
Net	4.5	9.9
Shipping	5.9	12.9

Environmental and Safety Characteristics

Characteristic	Description
Temperature
Operating	0 °C to +50 °C
Nonoperating	-30 °C to +70 °C
Humidity
Operating	≤ +40 °C: ≤80% > +40 °C to 50 °C: ≤60%
Altitude	Up to 10,000 ft./3,000 m
EMC Compliance
European Union	EU Council Directive 2004/108/EC
Safety	UL 61010-1:2004 CAN/CSA C22.2 No. 61010-1:2004 IEC 61010-1:2001
