Attenuation (probe only): 10X
DC attenuation accuracy (probe only): 10:1 ±2% (excludes offset error)
Typical characteristics:
Bandwidth (probe only): ≥4 GHz
Bandwidth (probe only): DC to ≥4 GHz
Rise time (probe only): ≤115 ps
Input capacitance: ≤0.8 pF
Input resistance: 40 kΩ
Input dynamic range: ±4.0 V
Input offset range: ±10 V
Maximum non-destructive input voltage: ±30 V (DC + peak AC)
Propagation delay: 5.3 ns
Physical characteristics:
Probe head size:
Height: 7.6 mm (0.30 in)
Width: 7.6 mm (0.30 in)
Length: 57.2 mm (2.25 in)
Other dimensions:
Cable length: 1300 mm (51 in)
Weight:
Unit: 1.55 kg (3.44 lbs); probes, accessories, and packaging
Net: 0.091 kg (0.2 lbs); probe only, using ME lab scale
Power requirements: The probe is powered directly by oscilloscopes with the TekVPI probe interface.
EMC, environment, and safety:
Temperature:
Operating: 0 °C to +50 °C (+32 °F to 122 °F)
Nonoperating: -40 °C to +71 °C (-40 °F to 160 °F)
Humidity:
Operating:
5% to 95% RH up to +30 °C (+86 °F)
5% to 85% RH at +30 °C to +50 °C (+86 °F to +122 °F), noncondensing
Nonoperating:
5% to 95% RH up to +30 °C (+86 °F)
5% to 85% RH at +30 °C to +75 °C (+86 °F to +167 °F), noncondensing
Altitude:
Operating: Up to 4,400 m (14,436 ft)
Nonoperating: Up to 12,192 m (40,000 ft)
Emissions compliance: EN 55011, Class A
Regulatory compliance labeling:
C-Tick (Australia/New Zealand)
CE (European Union)
WEEE (European Union)
