Channel
CH1 output voltage: 0 ~ 32 V, output current: 0 ~ 3.2 A
CH2 output voltage: 0 ~ 32 V, output current: 0 ~ 3.2 A
CH3 output voltage: 2.5 / 3.3 / 5.0 V, output current: 3.2 A
Display: 4.3 inch color TFT-LCD, 5 digits voltage 4 digits current
Resolution: 1 mV / 1 mA
Program Accuracy:
Voltage ± (0.03 %of reading + 10 mV)
Current ± (0.3 %of reading + 10 mA)
Readback Accuracy:
Voltage ± (0.03 %of reading + 10 mV)
Current Current ± (0.3 %of reading +10 mA)
Constant Voltage Mode
Line Regulation: ≤ 0.01%+ 3 mV
Load Regulation: ≤ 0.01%+ 3 mV
Ripple & Noise: ≤ 1 mVrms (5 Hz ~ 1 MHz)
Recovery Time: < 50 μs (50 %load change, minimum load 0.5 A)
Constant Current Mode
Line Regulation: ≤ 0.2 %+ 3 mA
Load Regulation: ≤ 0.2 %+ 3 mA
Ripple & Noise: ≤ 3 mArms
Parallel Mode
Line Regulation: ≤ 0.01%+ 3 mV
Load Regulation: ≤ 0.01%+ 3 mV
Series Mode
Line Regulation: ≤ 0.01%+ 5 mV
Load Regulation: ≤ 300 mV
CH3
Output Voltage: (2.5 / 3.3 / 5 V) ± 8 %
Line Regulation: ≤ 0.01%+ 3 mV
Load Regulation: ≤ 0.01%+ 3 mV
Ripple & Noise: ≤ 1 mVrms (5 Hz ~ 1 MHz)
Locking Key: Yes
Memory Save / Recall: 5 Sets
Max Output Power: 220 W
Power Source: AC 100 V / 120 V / 220 V / 230 V ± 10% 50/60 Hz
Standard Configuration: Interface USB Device, LAN
Insulation:
Case to Terminal ≥ 20 MΩ (DC 500 V)
Case to AC line ≥ 30 MΩ (DC 500 V)
Environmental
Operating Temperature: 0 °C to +40 °C
Storage Temperature: -10 °C to +70 °C
Humidity: 5% to 90% relative humidity (non-condensing) up to +30 °C.
Upper limit derates to 50% relative humidity (non-condensing) at +40 °C
Operating Altitude: 2000 m (Max)
Indoor Use only
Pollution Degree 2 (per IEC61010-1:2010)
Dimension: 225 (W) × 143 (H) × 278 (D) mm
Weight: ≈ 8.0 kg
