Infrared image output
Focus: manual
Infrared resolution: 160 x 120 pixels
Image refresh rate: 33 Hz
Super Resolution (IFOV): 2.1 mrad (Tele: 0.6 mrad)
Super Resolution (Pixel): 320 x 240 pixels
Geometric resolution (IFOV): 3.3 mrad (Tele: 1.0 mrad)
Minimum focus distance: 0.1 m (Tele: 0.5 m)
Field of view: 32° x 23°
Thermal sensitivity: ˂ 50 mK at +30 °C
Image output visual
Minimum focus distance: 0.4 m
Image size: 640 x 480 pixels
Image presentation
Display option: IR image only; real image only; IR image / real image
Number of colours: 10
Colours: 10 (iron, rainbow, rainbow HC, cold-hot, blue-red, grey, inverted grey, sepia, Testo, iron HT)
Display type: 3.5" LCD with 320 x 240 pixels
Video output: USB 2.0
Measurement
Reflected temperature: manual
Measuring range: -30 to +100°C; 0 to +350 °C (switchable)
High temperature measuring: +350 to +550 °C
Accuracy: ±2 °C, ±2 % of m.v. (±3 °C of m.v. at -30 to -22 °C)
Accuracy high temperature: ±3 % of m.v. at +350 to +550 °C
Measuring function
Surface moisture distribution: Included
Humidity measurement: Optional
Solar mode – manual: Included
Analysis function: Up to 2 measurement points, hot/cold spot recognition, isotherms, area measurement (min/max on area)
Imager equipment
Digital camera: Included
Video streaming: Included
Voice recording: wired headset
Laser: Included
Exchangeable lenses: 9° x 7°
Standard lens: 32° x 23°
Power-LED: Included
Imager storage
File format image: .bmt; export option in .bmp; .jpg; .png; .csv; .xls
Storage device: SD card 2GB (approx. 2.000 images)
Power supply
Battery type: Fast-charging, Li-ion battery can be changed on-site
Operating time: 4 h
Charging options: In instrument / charger (optional)
Mains operation: yes
Ambient Condition
Storage temperature: -30 °C; 60 °C
Operating temperature: -15 °C; 40 °C
Housing protection class: IP54
Vibration: 2G
Air humidity: 20 to 80 %RH non-condensing
Physical specification
Weight: 900 g
Tripod mounting: M6
Housing: ABS
Dimensions: 152 x 108 x 262
PC software
System requirements: Windows XP (Service Pack 3); Windows Vista; Windows 7 (Service Pack 1); Windows 8; Interface: USB 2.0
Standards, tests, warrenty
EU-/EG-guidelines: 2004/108/EG
Standard delivery: a robust case, professional software, soft case, carrying strap, SD card, USB cable, lens cleaning cloth, mains unit, rechargeable Li-ion battery,tripod adapter and headset
