Width: 0.64 mm
Height: 0.35 mm
Length: 1 mm
Fall Time: 3.4 ns
Rise Time: 1.3 ns
Technology: Si
Unit Weight: 0.400 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 1.01 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 500 mW
Vgs - Gate-Source Voltage: - 12 V, + 12 V
Typical Turn-On Delay Time: 3.3 ns
Typical Turn-Off Delay Time: 10.6 ns
Id - Continuous Drain Current: 1.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 2.4 S
Rds On - Drain-Source Resistance: 230 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 850 mV
