Shutdown: Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 26.800 mg
Amplifier Type: General Purpose Operational Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 2 V/us
THD plus Noise: 0.004 %
Number of Channels: 4 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.8 V
Ib - Input Bias Current: 5 pA
Operating Supply Current: 60 uA
Ios - Input Offset Current: 2 pA
Output Current per Channel: 40 mA
Vos - Input Offset Voltage: 1.6 mV
Maximum Dual Supply Voltage: +/- 2.75 V
Minimum Dual Supply Voltage: +/- 900 mV
GBP - Gain Bandwidth Product: 1 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 23 fA/sqrt Hz
en - Input Voltage Noise Density: 30 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 77 dB
PSRR - Power Supply Rejection Ratio: 105 dB
