Color: UV
Nominal Wavelength(a): 385 nm
Bandwidth (FWHM): 12 nm
Maximum Current (CW): 1700 mA
Forward Voltage: 3.9 V
Electrical Power (Max): 6630 mW
Emitter Size: 1.4 mm x 1.4 mm
Typical Lifetime: >10 000 h
Operating Temperature (Non-Condensing): 0 to 40 °C
Storage Temperature: -40 to 70 °C
Risk Group(b): RG3 – High Risk Group
***a. Value is approximate.
b. According to the standard IEC 62471:2006, Photobiological Safety of Lamps and Lamp Systems
Total Beam Power(a): 660 mW
Beam Diameter(a): 44 mm
Compatible Microscopes: Zeiss Axioskop
***a. Values are approximate.
b. Measured at Maximum Current.
