THORLABS TLX2 Fiber-Coupled, Benchtop Tunable Laser Sources (1570 - 1609 nm)

Laser Tuning:

- Tunable Wavelength Range: 1570 - 1609 nm

- Tunable Frequency Range: 186.35 - 190.95 THz

Laser Specifications:

- Parameter Min:

Optical Output Power(a): 12.5 dBm

Frequency Accuracy: -1.5 GHz

Tuning Resolution: -

Fine Tuning Resolution: -

Tuning Speed (Between Wavelengths): -

Fine Tuning Range: -30 GHz

Side Mode Suppression Ratio: 40 dB

Optical Signal Noise Ratio: 40 dB

Intrinsic Linewidth: -

Relative Intensity Noise: -

Back Reflection: -

Polarization Extinction Ratio: 18 dB

- Parameter Typ:

Optical Output Power(a): 13.5 dBm

Frequency Accuracy: -

Tuning Resolution: 50 GHz

Fine Tuning Resolution: 1 MHz

Tuning Speed (Between Wavelengths): 10s

Fine Tuning Range: -

Side Mode Suppression Ratio: 55 dB

Optical Signal Noise Ratio: 60 dB

Intrinsic Linewidth: 10 kHz

Relative Intensity Noise: -

Back Reflection: -

Polarization Extinction Ratio: -

- Parameter Max:

Optical Output Power(a): 14.5 dBm

Frequency Accuracy: 1.5 GHz

Tuning Resolution: -

Fine Tuning Resolution: 30 GHz

Tuning Speed (Between Wavelengths): -

Fine Tuning Range: -

Side Mode Suppression Ratio: -

Optical Signal Noise Ratio: -

Intrinsic Linewidth: 15 kHz

Relative Intensity Noise: -145 dB/Hz

Back Reflection: -14 dB

Polarization Extinction Ratio: -

(a) At the VOA Out Bulkhead
