TOB TOB-AWM-3270C Supercapacitor And Cylinder Battery Winding Machine (6KW)
Manufacturer: TOB Model: TOB-AWM-3270C Origin: China Guarantee: 12 Month - Request a Quotation
- Request a Quotation
- Contact
Source voltage: AC220V/50Hz/Single phase. Customized according country request
Power: 6KW
Compressed air: 0.45～0.6Mpa
Operating environment
Temperature: 20～35℃
Humidity: 30～55％HR
Tab welding skewness: ±3°
Welding tension: ≥15N
Cutter knife life
Cathode 500000 times with repair
Anode 200000 times with repair
According to tab thickness
Output: 4-5pcs/min according to battery model
Dimension (L*W*H): 2400*1700*1900mm
Weight: 1500kg
