Power: 9KW
Furnace tube size(mm): 300X250X250
Dimension: 650X610X940
Power supply voltage: 380V
Phase number: Single-phase
Heating element: 1800 type silicon molybdenum rod
Temperature control mode
1.Yudian temperature control: 30 sections can only use PID temperature regulation.
2.FP93 temperature control (from Japan)
Control accuracy: +/- 1 ℃
Triggers
1.Phase trigger (with soft start and current limiting function)
2.Current limiting function: furnace transformer secondary current through the post is limited to 160A,
3.Soft-start function
SCR: 106 / 16E Germany Semikron
Max temperature: 1600℃
Rated temperature: 1550 ℃
Heating rate: ≤20 ℃ / Min (available upon request modification)
Recommended heating rate: ≤10 ℃ / Min
Thermocouple Type: Type B
Certification: CE
Surrounding surface temperature: ≤45℃
Maximum temperature use in a variety of atmosphere
Atmosphere Max temperature
NO2,CO2,O2,Air 1600℃
He,Ar,Ne 1550℃
SO2 1500℃
CO,N2 1500℃
Wet H2 1300℃
Dry H2 1250
