Display: 7 inch TFT LCD Display 800×RGB×480
AC Parameters: Cp/Cs, Lp/Ls, Rp/Rs, |Z|, |Y|, R, X, G, B, θ, D, Q, Vac, Iac
DC Parameters: Rdc, Vdc, Idc
Test Frequency:
+ Range: 4Hz-8.5MHz
+ Resolution: 1mHz
Test Electric Level
+ AC Voltage: 4Hz-1MHz：5mV-2Vrms
1MHz-8.5MHz：5mV-1Vrms
+ Resolution: 100μV
+ AC Current : 4Hz-2MHz：50μA-20mArms
2MHz-8.5MHz：50μA-10mArms
+ Resolution: 1μA
+ DC Voltage: 100mV-2V
+ Resolution: 100μV
DC Bias
+ Voltage: 0V-±10V
+ Resolution: 100μV
+ Current: 0mA-±100mA
+ Resolution: 1μA
Cs, Cp : ±1.00000aF-999.999EF
Ls, Lp: ±1.000000aH-999.999EH
D: ±0.00001-9.99999
Q: ±0.01-99999.9
R, Rs, Rp, X, Z, Rdc: ±1.00000aΩ-999.999EΩ
G, B, Y: ±1.00000aS-99.9999ES
Vdc: ±1.000000aV-999.9999EV
Idc: ±1.00000aA-999.999EA
θr: ±1.00000rad-3.14159rad
θd: ±0.0001deg-180.000deg
Δ%: ±0.0001%-999.999%
