Toshiba DF2B5SL,L3F ESD Suppressors ESD protection diode 5.5A +/-17kV
Manufacturer: Toshiba Model: DF2B5SL,L3F - Contact
Polarity: Bidirectional
Unit Weight: 0.200 mg
Clamping Voltage: 11.5 V
Breakdown Voltage: 4.5 V
Termination Style: SMD/SMT
Number of Channels: 1 Channel
Cd - Diode Capacitance: 7.2 pF
Ipp - Peak Pulse Current: 5.5 A
Vesd - Voltage ESD Air Gap: 17 kV
Vesd - Voltage ESD Contact: 17 kV
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Pppm - Peak Pulse Power Dissipation: 77 W
