Width: 6.4 mm
Height: 3.5 mm
Length: 19.25 mm
Function: NAND
Unit Weight: 1.620 g
Logic Family: HC
Logic Function: NAND
Mounting Style: Through Hole
Output Current: 25 mA
Output Voltage: 0 V to 6 V
Number of Gates: 4 Gate
Supply Voltage - Max: 6 V
Supply Voltage - Min: 2 V
Number of Input Lines: 8 Input
Number of Output Lines: 4 Output
Pd - Power Dissipation: 500 mW
Propagation Delay Time: 6 ns
Low Level Output Current: 5.2 mA
Operating Supply Voltage: 2.5 V, 3.3 V, 5 V
High Level Output Current: - 5.2 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
