Function: Shift Register
Input Type: Serial / Parallel
Logic Type: CMOS
Output Type: Serial
Unit Weight: 180 mg
Counter Type: Parallel
Logic Family: HC
Mounting Style: SMD/SMT
Number of Bits: 8 bit
Counting Sequence: Serial/Parallel to Serial
Number of Circuits: 1 Circuit
Supply Voltage - Max: 6 V
Supply Voltage - Min: 2 V
Number of Input Lines: 8
Number of Output Lines: 1
Propagation Delay Time: 15 ns
Low Level Output Current: 5.2 mA
Operating Supply Voltage: 2 V to 6 V
High Level Output Current: - 5.2 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
