Width: 5 mm
Height: 26 mm
Length: 20 mm
Fall Time: 125 ns
Rise Time: 130 ns
Technology: Si
Unit Weight: 7 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 360 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 797 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 230 ns
Typical Turn-Off Delay Time: 690 ns
Id - Continuous Drain Current: 100 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 15 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 3.7 V
