Width: 4.5 mm
Height: 15 mm
Length: 10 mm
Fall Time: 11 ns
Rise Time: 20 ns
Technology: Si
Unit Weight: 2 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 16 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 35 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 40 ns
Typical Turn-Off Delay Time: 60 ns
Id - Continuous Drain Current: 7.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 1 S
Rds On - Drain-Source Resistance: 760 mOhms
Vds - Drain-Source Breakdown Voltage: 500 V
Vgs th - Gate-Source Threshold Voltage: 4.4 V
