Width: 5 mm
Height: 0.95 mm
Length: 5 mm
Fall Time: 15 ns
Rise Time: 11 ns
Technology: Si
Unit Weight: 83 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 72 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 142 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 30 ns
Typical Turn-Off Delay Time: 56 ns
Id - Continuous Drain Current: 168 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 2.6 mOhms
Vds - Drain-Source Breakdown Voltage: 75 V
Vgs th - Gate-Source Threshold Voltage: 2 V
