- Rated Voltage: 2.5 kV:
Rated Current: 100~200 mA
Rated Power: 250~500 VA
Max Power: 300~600 VA
Load Resistance: 12.5~25 kΩ
- Rated Voltage: 5 kV:
Rated Current: 20~100 mA
Rated Power: 100~500 VA
Max Power: 120~600 VA
Load Resistance: 50~250 kΩ
- Rated Voltage: 10 kV:
Rated Current: 10~50 mA
Rated Power: 100~500 VA
Max Power: 120~600 VA
Load Resistance: 200~1000 kΩ
- Rated Voltage: 15 kV:
Rated Current: 7~30 mA
Rated Power: 100~450 VA
Max Power: 120~540 VA
Load Resistance: 450~2250 kΩ
- General Specifications:
Power Supply: AC ( 220 ± 22 ) V，( 50 ± 2 ) Hz
Temperature Performance
Working temperature：0℃~45℃;
Storage temperature：-20℃~70℃
Humidity Performance
Working humidity：< 80% @ 30℃，< 70% @ 40℃，< 40% @ 50℃
Storage humidity：(20%~80%) R•H，non-condensing
