Certificates: CE, RoHS
Test frequency: 100Hz, 120Hz, 1kHz, 10kHz, 100kHz
Test signal level: 0.1Vrms, 0.3Vrms, 1Vrms
Output impedance: 100Ω
Measurement parameters: Primary: L/C/R/Z/DCR , Secondary: D/Q/θ/ESR
Auto LCR: √
Test terminals: Three-terminal test jacks, five-terminal test sockets
Test rate: Fast (20 times/s), medium (5 times/s), or slow (2 times/s)
DCR test speed: Fast (20 times/s), medium (5 times/s), or slow (2 times/s)
Ranging mode: Auto/hold
Tolerance range: 1%~20%
Testing circuit mode: Series/parallel mode
Clearing correction: Open/short circuit
Fuse of test ports: 0.1A/250V
Communication interface: Mini-USB
LED alarm for tolerance
(pass: green; fail: red): √
Display range
Maximum reading: 99999
Minimum resolution: 0.0001
Maximum accuracy: 0.001
L: 0.00μH~99.999H
C: 0.00pF~99.999mF
Z/R: 0.0000Ω~9.9999MΩ
ESR: 0.0000Ω~999.99Ω
D: 0.0000~9.9999
Q: 0.0000~99999
θ: -179.9°~179.9°
DCR: 0.01mΩ--20.000MΩ
Temperature coefficient: 0.1× (specified accuracy) /°C (0°C~18°C or 28°C~40°C)
General Characteristics
Power: 3.7V 1800mAh lithium polymer battery; Input: 220V (1±10%), 50Hz (1±5%); Mini-USB output: 5V, 1A
Display: 2.8' TFT LCD 320X240
Product net weight: 420g
Product size: 93mm x 192mm x 44mm
Standard accessories: Short circuit board (UTR-001), USB cable, 5V 1A power adapter, Alligator clip test leads with rubber plugs (UTR-002)(UT622A), English manual
Standard individual packing: Gift box
Standard quantity per carton: 10pcs
Standard carton measurement: 370mm × 305mm × 475mm
Standard carton gross weight: 13.2kg
