Display: 2.8” TFT (320×240)
IR resolution (Pixels): 256×192
Super resolution (Pixels): Yes (512×384)
Spectral range: 8~14µm
Pixel size: 12µm
Frame rate: ≤25Hz
Thermal sensitivity (NETD): ≤50mK
Focus: Focus Free
Field of view (FOV): 56° (H) × 42° (V)
Spatial resolution (IFOV): 3.75mrad
Temperature measurement range: -20℃ ~ 550℃
Accuracy:
From 20℃ to 120℃: ±1.5℃ or ±1.5%, whichever is greater
From -10℃ to 20℃ and 120℃ to 550℃: ±2℃ or ±2%, whichever is greater
Functions
Color palette: White Hot, Black Hot, Red Hot, Ironbow, Lava, Rainbow, Rainbow HC
Image mode: Thermal, Visual image, T-Mix fusion, PIP
On screen analyzer: 5 Points / 3 Rectangles
HI/LO temperature alarm: LCD animation, LED flashlight, Buzzer
HI/LO temperature tracking: √
Digital camera resolution: 2MP
Video recording:√
Wi-Fi / Wi-Fi live streaming:√
LED lighting:√
Analysis software: PC + APP
General Characteristics
Battery: 5000mAh rechargeable Li-ion battery
Operating time: ≥7 hours
USB: Type-C
Storage: Built-in 32GB
Image / video storage format: JPG / MP4
Protection: IP65 & 2m drop proof
Certificates: CE, FCC, RoHS
Languages: EN, FR, DE, IT, ES, SV, PL, CZ
Weight: 600g
Dimension: 236mm × 75.5mm × 86mm
