Mechanical Data:
Dimension: With the housing: 54.0 × 137.3 × 125.5 mm (2.13 × 5.41 × 4.94 in)
Weight: 340 g (11.99 oz) without the USB cabling and housing
Radome Material: HDPE
Connector 1: K jack (female)
Connector 2: USB Type C with locking screw
Environmental Data:
Operating Temperature: –20 to +65 °C
Electrical Data:
Frequency Range: 24000 to 40000 MHz
Gain: 18 dBi typical (3 dBi from the antenna and 15 dBi from the integrated LNA)
Azimuth Gain Variation: ±1 dB
Azimuth Beam Width: 360°
3 dB Vertical Beam Width: 45°
P1dB: 11 dBm
Return Loss: 10 dB
RF Input Power: –8 dBm maximum
Damage RF Input Power: –3 dBm maximum
Supply Voltage: 4.8 V DC minimum, 5 V DC typical, 20 V DC maximum
Supply Current: 150 mA typical
