Insulation Resistance Tester
Rated voltage: 50V
Measurement range: 4MΩ / 40MΩ / 400MΩ / 1GΩ
Range: 0.05MΩ ~ 1GΩ
Precision: ±(5%+5)
Resolution: 0.001MΩ ~ 0.001GΩ
Rated voltage: 100V
Measurement range: 4MΩ / 40MΩ / 400MΩ / 2GΩ
Range: 0.1MΩ ~ 2GΩ
Precision: ±(5%+5)
Resolution: 0.001MΩ ~ 0.001GΩ
Rated voltage: 250V
Measurement range: 4MΩ / 40MΩ / 400MΩ / 4GΩ / 5GΩ
Range: 0.25MΩ ~ 5GΩ
Precision: 0.25MΩ ~ 399.9MΩ: ±(3%+5)
Rated voltage: 500V
Measurement range: 4MΩ / 40MΩ / 400MΩ / 4GΩ / 10GΩ
Range: 0.5MΩ ~ 10GΩ
Precision: 0.4GΩ ~ 2GΩ: ±(5%+5)
Resolution: 0.001MΩ ~ 0.01Ω
Rated voltage: 1000V
Measurement range: 4MΩ / 40MΩ / 400MΩ / 4GΩ / 20GΩ
Range: 1MΩ ~ 20GΩ
Precision: 2.001GΩ ~ 20GΩ: ±(10%+5)
Multimeter
DC voltage: 6V / 60V / 600V
Accuracy: ±(0.5%+4)
DC voltage: 1000V
Accuracy: ±(1.0%+6)
AC voltage: 6V / 60V / 600V
Accuracy: ±(0.8%+10)
AC voltage: 750V
Accuracy: ±(1.0%+10)
Resistor: 600Ω
Accuracy: ±(0.8%+5)
Resistor: 6kΩ / 60kΩ / 600kΩ / 6MΩ
Accuracy: ±(0.8%+4)
Resistor: 60MΩ
Accuracy: ±(2.0%+5)
Capacitor: 10nF
Accuracy: ±(3.0%+20)
Capacitor: 100nF / 1000nF / 10uF / 100uF / 1000uF
Accuracy: ±(3.0%+5)
Capacitor: 10mF / 100mF
Accuracy: ±(8.0%+5)
General Function
Sampling rate: About 3 times per second
Overrange: Display “OL”
Low pressure: Yes
Diode: Yes
Data retention: Yes
On-off beeping: Yes
Backlight display: Yes
True effective value: Yes
Automatic shutdown: About 15 minutes after powering on
Power supply: 10440 2 × 3.7V lithium batteries
Size: 189 × 88 × 56mm
Weight: Approximately 395g
