Fall Time: 25 ns
Rise Time: 29 ns
Technology: Si
Channel Mode: Enhancement
REACH - SVHC: Details
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 18 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 42 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 9.6 ns
Typical Turn-Off Delay Time: 21 ns
Id - Continuous Drain Current: 5.6 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 1.5 S
Rds On - Drain-Source Resistance: 600 mOhms
Vds - Drain-Source Breakdown Voltage: 100 V
Vgs th - Gate-Source Threshold Voltage: 2 V
