Vishay Roederstein MKP1847615314P5 Metallized Polypropylene AC Film Capacitors MKP 15uF +/-5% 310Vac Pitch 37,5 Pins4
Manufacturer: Vishay Roederstein Model: MKP1847615314P5 - Contact
Life: 60000 Hour
Width: 30 mm (1.181 in)
Height: 45 mm (1.772 in)
Length: 42 mm (1.654 in)
Tolerance: 5 %
Dielectric: Polypropylene (PP)
Lead Style: Straight
Capacitance: 15 uF
Unit Weight: 58 g
Lead Spacing: 37.5 mm (1.476 in)
Lead Diameter: 1 mm
Number of Pins: 4 Pin
Termination Style: Radial
Voltage Rating AC: 310 VAC
Voltage Rating DC: 630 VDC
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
