Fall Time: 4 ns
Rise Time: 5 ns
Technology: Si
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: TrenchFET Gen IV Power MOSFET
Qg - Gate Charge: 17.4 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 29 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 9 ns
Typical Turn-Off Delay Time: 19 ns
Id - Continuous Drain Current: 20 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 33 S
Rds On - Drain-Source Resistance: 30.4 mOhms
Vds - Drain-Source Breakdown Voltage: 100 V
Vgs th - Gate-Source Threshold Voltage: 2.4 V
