Fall Time: 10 ns
Rise Time: 11 ns
Technology: Si
Unit Weight: 506.600 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 106 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 83 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 15 ns
Typical Turn-Off Delay Time: 44 ns
Id - Continuous Drain Current: 12 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 16 S
Rds On - Drain-Source Resistance: 213 mOhms
Vds - Drain-Source Breakdown Voltage: 200 V
Vgs th - Gate-Source Threshold Voltage: 3.5 V
