Fall Time: 36 ns
Rise Time: 100 ns
Technology: Si
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 110 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 375 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 40 ns
Typical Turn-Off Delay Time: 120 ns
Id - Continuous Drain Current: 150 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 12.4 mOhms
Vds - Drain-Source Breakdown Voltage: 200 V
Vgs th - Gate-Source Threshold Voltage: 4 V
