Measurement Frequency: 10Hz ~ 5MHz. Frequency Resolution: ≦1mHz
AC Drive:
AC Voltage Range: 10mV~5Vrms
AC Voltage Resolution: <1% of setting
AC Current Range: 200uA~200mArms
AC Current Resolution: <1% of setting
Automatic Level Control(ALC): ON or OFF. Maintains constant voltage or constant current at the Device Under Test
Source Resistance: Normal Mode: 50Ω ; Boost Mode: 25Ω
Basic Accuracy: 0.05%
DC Resistance(Rdc):
DC Voltage Range: 10mV~5V
DC Voltage Resolution: 1mV
DC Resistance Resolution: 10uΩ
Built-in DC Bias: Maximum current: Reserved temporarily
External DC bias: Maximum voltage: Reserved temporarily
External DC Bias Current using 3265B or 3265BQ* DC Bias Units:
Maximum Current and Frequency: 300A at 500kHz; 250A at 1MHz; 50A at 3MHz*
DC Bias Current Resolution: 25mA
