Electrical Specifications:
- Impedance Measurement
Range: 0.05mΩ ~ 4Ω (4 range)/1uΩ resolution
Accuracy : ±0.8%rdg ±10dgts
Voltage Range : max 100V
Ah range : 5 ~ 6000 Ah
- Voltage Measurement : Differential Input
Range : 4V, 40V, 300V (3 range)
Accuracy : ±0.5%rdg ±5dgts
- DC Current(Float Current) Measurement.CT
Range : 40A/400A
Accuracy : ±1%rdg ±5dgts (CT Accuracy added)
- AC Current(Ripple Current) Measurement.CT *Option
Range : 40A/400A
Accuracy : ±1%rdg ±5dgts (CT Accuracy added)
- Temperature
Range : -10°C ~ 100°C/ 14°F ~ 212°F
Accuracy : ±2°C ±3.6°F
Battery Temperature Measurement : Internal Sensor.
Guaranteed Accuracy : 23°C +/-5°C, non-condensing
General Specifications
- Display : 3.8" Graphic Monochrome LCD Module(320*240)
- Input Method : Differential (Impedance, DC Voltage)
- Auto Power OFF : User Select at User mode
- Maxim Voltage Input : 300V DC
- Interface : USB 2.0 (Standard), Bluetooth (Option) Wi-Fi (Option)
- Operating Temperature : 0 ~ 40°C, 80% RH or Less
- Continuous Operating Time : 6 hours
- Power Supply : 7.2V, 2.7A NiMH Battery Pack (2)
- Line Power : 12V, 1A Adapter
- Dimensions: : 107m (W) x 220mm (H) x 55mm(D) / 4.2”x 8.3”x 2.2”
- Weight (Main Unit only) : 1.2kg / 2.6 Ibs
Accessories
- Standard Accessories :
4 Terminal Battery Test Lead set (Pin type)
Ni-MH Rechargeable Battery Pack (installed)
USB PC Interface Package
(Program and User Manual in CD. USB Cable)
Hardcopy User Manual, O
Ohm Adjustment Bar, ADC Power Adapter
and Internal Charger, Carrying Bag with Shoulder Strap
- Optional Accessories :
4 Terminal Battery Test Lead (Clamp type)
ADC Current Adapter
