Max.swing over bed: Ф320mm
Max.swing over carriage: Ф180mm
Max. cutting length: 450mm
Rail width: 284mm
Spindle nose: A2-5
Spindle bore: Ф56mm
Taper of spindle bore: 1:20
Chuck size: 6″
Range of spindle speed: 150-4200rpm
X-axis travel: 190mm
Z-axis travel: 450mm
X/Z rapid speed: 20/20m/min
Electronic turret: 8
Stroke of tailstock sleeve: 80mm
Diameter/Hole of tailstock sleeve: Ф60mm/MT4
Main motor power: 4kW (optiona:5.5kw)
Coolant pump power: 370w
Overall dimensions (L x W x H): 2300x1550x1750mm
Packing size (L x W x H): 2500x1750x2000mm
Net weight: 2200kg
Gross weight: 2600kg
