Outputchannel-1/Outputchannel-2
Rated Power: 400kW
Peak Power: 520kW
Output Voltage: 24 ～1000V
Rated Voltage: 500V
Rated Current: ±800A
Peak Current: ±1040A
AC characteristic
Input mode: 3-phase 3-wire +PE
Voltage: AC380V±10%
Frequency: 50Hz±5Hz
Power factor: ≥0.99
Total current harmonic: ≤3%
DC characteristic
Output accuracy: ≤±0.1%FS
Source effect: ≤0.1%FS
Load effect: ≤0.1%FS
Ripple (Vrms): ≤0.2%FS
Response time: ≤3mS（10%~90% sudden loading）
Feedback characteristic
Alternating current voltage: AC 342V~420V(Allowable voltage range)
Ac frequency: 45Hz~55Hz (Allowable grid frequency)
Power factor: ≥0.99
Total harmonic content: ≤3%
Switching timer: ≤6mS(+90%~-90% switching)
Feedback power: Supports full scale power feedback
Communication interface: RS485,CAN, LAN
Safety feature
Insulation resistance: ≥20MΩ
Voltage resistance: 2000VDC test 60S, no flashover, breakdown
Ground resistance: ≤100mΩ
Noise: ≤65dB
Protection grade: IP21(Indoor)
Cooling mode: Forced air cooling
Working environment
Ambient temperature: -10~45℃
Ambient humidity: 10%~90%(no condensation)
Altitude: ≤2000m
