Discharge voltage range: 10-300Vdc
Discharge current range:
Range 1: 10-20V Current: 0-40A continuously adjustable
Range 2: 20-40V Current: 0-80A continuously adjustable
Range 3: 40-60V current: 0-150A continuously adjustable
Range 4: 60-120V Current: 0-100A continuously adjustable
Range 5: 120-300V current: 0-60A continuously adjustable
Power Input-AC: Single-phase AC 220V, the frequency range is 40-60Hz.
Operation mode: Touch screen
Display: 7 inch TFT LCD screen, resistive touch screen, resolution 1024x600
Communication: RS485x1
Internal data storage: 128MBit
Voltage measurement accuracy: ±0.5%FS+0.1V Max.
Current measurement accuracy: ±1%FS+0.1A
Group voltage display accuracy: 0.01V
Group current display accuracy: 0.1A
Discharge current control accuracy: ±1%FS
Protection: Over temperature, over current, current out of control trigger shutdown protection
Safety test
Withstand-voltage test:
- AC input-chassis: 2200Vdc 1min AC input-chassis
- DC input-output: 2200Vdc 1min DC input-chassis
Working temperature
- Cooling: Forced air cooling
- Temperature: Operating temperature range: -5~50℃; storage temperature: -40~70℃
- Humidity: Relative Humidity 0~90%(40±2℃)
- Altitude: Rated 2000 meters above sea level
