Width: 50.8 mm (2 in)
Height: 30.5 mm (1.201 in)
Length: 101.6 mm (4 in)
Industry: Medical, Industrial
Approvals: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Compliance: ANSI/AAMI, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Efficiency: 80 %
Unit Weight: 150 g
Output Power: 60 W
Input Voltage: 90 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 3 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 8 A
Output Current-Channel 2: 1.5 A
Output Current-Channel 3: 500 mA
Output Voltage-Channel 1: 5 VDC
Output Voltage-Channel 2: 24 VDC
Operating Temperature Range: 0 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
