Width: 50.8 mm
Height: 31.8 mm
Length: 101.6 mm
Industry: Medical, Industrial
Approvals: ANSI/AAMI, CSA, EN60950--1, ES60601-1, IEC60601-1, IEC60950-1, TUV
Compliance: ANSI/AAMI, CSA, EN60950--1, ES60601-1, IEC60601-1, IEC60950-1, TUV
Efficiency: 90 %
Unit Weight: 461.506 g
Output Power: 100 W
Input Voltage: 80 VAC to 264 VAC
Mounting Style: Panel
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 4.2 A
Output Voltage-Channel 1: 24 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
