Width: 101.6 mm (4 in)
Height: 101.6 mm (4 in)
Length: 323.9 mm (12.752 in)
Industry: Medical
Approvals: ANSI/AAMI ES60601-1, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Compliance: ANSI/AAMI ES60601-1, CSA/cUL, EN60601-1, EN60950-1, UL60950-1
Efficiency: 90 %
Output Power: 1.5 kW
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 2 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 50 A
Output Current-Channel 2: 1 A
Output Voltage-Channel 1: 24 VDC
Output Voltage-Channel 2: 5 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
