Aperture: 1.5mm, 2mm, 4mm, 6mm
Battery: Lithium Ion, 7.4VDC, 2200mAh
BestMatch Feature: No
Calibration Automatic on integrated white reference
Communication Interface: USB 2.0; Bluetooth (optional) - Class II
Connectivity: USB, Bluetooth
Density Range: 0.0 D – 3.0 D
Density Standards: Status A, E, I, T and G
Dimensions (length, width, height): 18 cm x 7.8 cm x 7.6 cm
7.1" x 3.1" x 3.0"
Humidity: 30 to 85% RH (non-condensing)
Industry Standards: ISO 5-4:2009(E), ISO 13655:2009
Instrument Display: Color touch-screen, 320 x 240 pixels
Languages Supported: Chinese Simplified, Chinese Traditional, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenian, Spanish, Swedish, Turkish, Vietnamese
Light Source: Gas filled tungsten (illuminant type A) and UV LED
Macintosh: MacOS X 10.10, 10.11, 10.12, 10.13
Measurement Geometry: 45°/0° ring illumination optics, ISO 5-4:2009(E)
Measurement Time: < 1 sec
NetProfiler Support: No
Operating Temperature Range: 10°C to 35°C; 50°F to 95°F
PantoneLIVE Support: Yes
Pass / Fail: Yes
Short Term Repeatability - Density: "+/- 0.01 D for CMYK
Software Development Kit: Yes
Spectral Analyzer: DRS spectral engine
Spectral Interval: 10 nm
Spectral Range: 400 nm to 700 nm
Storage Temperature Range: -20° to 50°C; -4° to 122°F
Voltage: 12 VDC at 2.5 A
Weight: 700 g; 1.6 lbs.
What's Included?: USB cable, power supply, CD with software and documentation, docking/charging station, quick start guide, carrying case, device certificate
