Color Differences: CIE1976ΔE*ab、ΔE94、ΔE2000，ΔEcmc
Color Spaces: CIEL*a*b*、CIEL*C*h
Illuminants: D50
Import/Export Format: CxF3
Observers: 2°
Spectral Interval: 10 nm
Voltage: 12 VDC @ 2.5 A
Aperture: 2mm
Battery : Lithium Ion, 7.4VDC, 2200mAh
BestMatch Feature: No
Calibration: Automatic on integrated white reference
Communication Interface: USB 2.0
Connectivity: USB 2.0
Density Range: 0.0 D – 3.0 D
Density Standards: Status A, E, I, T and G
Dimensions (length, width, height):
18 cm x 7.8 cm x 7.6 cm
7.1" x 3.1" x 3.0"
Embedded NetProfiler Support: No
G7 Certification: No
Japan Color Certification Job: Yes
Library Function: No
Humidity: 30 to 85% RH (non-condensing)
Industry Standards: ISO 5-4:2009(E), ISO 13655:2009
Instrument Display: Color touch-screen, 320 x 240 pixels
Internal Temperature & Humidity Sensor: Internal Temperature & Humidity Sensor
Languages Supported: Chinese Simplified, Chinese Traditional, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenian, Spanish, Swedish, Turkish, Vietnamese
Light Source: Gas filled tungsten (illuminant type A) and UV LED
Measurement Conditions: M0, M1 (part 1), M1 (part 2) , M2, M3; also available in Xp variant for flexible packaging substrates
Measurement Geometry: 45°/0° ring illumination optics, ISO 5-4:2009(E)
Measurement Time: < 1 sec
NetProfiler Support: No
Operating Temperature Range:
10°C to 35°C
50°F to 95°F
PantoneLIVE Support: Yes
Pass / Fail: Yes
Service Indicator: Certification Reminder
Short Term Repeatability - Density: "+/- 0.01 D for CMYK (Status E or Status T measurements, maximum error compared to mean value of 10 measurements every 5 seconds at 2.0 D except for M3 Yellow at 1.7 D)"
Software Development Kit: Yes
Spectral Analyzer: DRS spectral engine
Spectral Range: 400 nm to 700 nm
Spectral Reporting: 400nm to 700nm with 10nm interval
Storage Temperature Range:
-20° to 50°C
-4° to 122°F
User Experience: Start-up wizard, configurable, upgradable
Weight:
700 g
1.6 lbs.
What's Included?: USB cable, power supply, CD with software and documentation, docking/charging station, quick start guide, carrying case, device certificate
Windows Windows XP (32bit), Windows 7 (32 and 64 bit), Windows 8 (32 and 64 bit), Windows 10 (32 and 64 bit)
