Linear scan distribution: Sweep test range: (10Hz) - (10MHz) 40000 sweep point, resolution of 0.25kHz, 0.5kHz and 1kHz
Segmented sweep test distribution: Segmented sweep test distribution
Segmented sweep test distribution
Sweep test range: (0.5kHz) - (1MHz), 2000 sweep point;
(0.5kHz) - (10kHz)
(10kHz) - (100kHz)
(100kHz) - (500kHz)
(500kHz) - (1000kHz)
Amplitude test range: (-120dB) to (+20dB)
Amplitude test accuracy: 0.1dB
Scanning frequency accuracy: 0.0001
Signal input impedance: 1MΩ
Signal output impedance: 50Ω
Signal output amplitude: ± 20V
In-phase test repetition rate: 0.999
Instrument size: 300X340X120 (mm)
Instrument aluminum alloy box size: 310X400X330 (mm)
Weight: 10Kg
