Width: 10.00 mm
Height: 4.50 mm
Length: 28.60 mm
Fall Time: 33 ns
Rise Time: 24 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 37 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 1.92 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 13 ns
Typical Turn-Off Delay Time: 48 ns
Id - Continuous Drain Current: 10 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 15 S
Rds On - Drain-Source Resistance: 750 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 4 V
