Operating temperature range: -30 to +80°C
Temperature control accuracy: ±0.1°C
Temperature distribution accuracy: ±0.3°C
Temperature indicating unit: 0.1°C
Cooling capacity: Approx. 420W (361Kcal/h), at fluid temp.15°C
Temperature control: PID control
Operation function: Fixed temp., Auto stop , Auto start operations
Temperature sensor: Temp. controller: Pt thermal resistance, Overheat protection: K thermocouple
Temperature setting, display: Digital setting and display
Refrigerator, refrigerant: Air cooling 300W, R404A
Unit circulation ability(50/60Hz) Pump: max. Flow 2.8/3.2L/min.
Unit circulation ability(50/60Hz) Pump: max. Lift 1.1/1.4m
Heater: 850W
External circulation nozzle: O.D.10.5mm of water outlet and return port
Operating environmental temp. Range: 5 to 30°C
Safety device: Overcurrent ELB, Self-diagnosis, Refrigerator overload protector, Refrigerator delay timer of protection, Refrigerator pressure detection, Float switch preventing pump idling, Auto overheat protection, Overheat protector, Key lock, etc..
Other functions: Drain cock, Condenser filter, Calibration off-set, RS485 external communication, Refrigerator pressure indicator, Power outage compensation, Temp. output terminal
Accessories: Top cover, Drain hose, Overflow hose, Shelf plate
Internal dimensions（W×D×H mm): 150×300×170mm
External dimensions（W×D×H mm）: 434×472×883mm
Remarks(dimensions): Bath effective dimension W120×D140×H140mm ・ Bath capacity 6L
Power Source: AC220V 6A
Single-phase with step down transformer
Weight: 46kg
