Temp. adjusting range: 40 to 220°C (inlet temperature), 0 to 60°C (Outlet temperature)
Temperature adjusting accuracy: Inlet temperature±1°C
Spraying system: Two-way nozzle, Nozzle No. 1A as standard
Drying air amount adjusting range: 0 to 0.7m3/min
Spray air pressure adjusting range: 0 to 0.3MPa
Liquid sending pump flow rate range: 0 to 26mL/min
External output: Inlet temperature, Outlet temperature, Temperature outlet (4-20 mA)
Automatic lift: Moving up/down of glass chamber automatic lift
Temperature adjusting device: PID digital temperature adjusting device
Touch panel: Blower, Heater, Liquid sending pump, Pulse jet switch, Error display
Control select switch: Inlet temperature, Output temperature control switch (Outlet temp. control is conditional)
Heater: 2.0 kW (at 200V) to 2.88 kW (at 240V)
Liquid sending pump: Fixed amount peristaltic pump
Spraying air pump: Spraying air compressor (Sold separately) is used.
Service outlet: For stirrer: AC100V, Max. 2A
Suction blower: Bypass blower, Brushless DC motor
Filter: Suction filter, Exhaust filter
Recovery of solvent: Solvent recovery unit GAS410 (sold separately) is used.
Spray nozzle cooling mechanism: Connector: Nipple×2, O.D.:ø10.5 mm
Spray air connection diameter: Nipple diameter:ø7 mm
Exhaust connecting diameter: ø50mm
Safety device: Inlet/Outlet temperature overheat, Sample feed reverse rotation mechanism, Over current electric leakage breaker, Nozzle connection error
Accessories: Silicon tube (with a stopper)×3, Tiron tube (with a stopper)×2 Exhaust duct (with one hose band)×1, Outlet temperature sensor, Spray air tube, Sample box, Static electricity removal earth, Teflon braided hose 5m (with two hose bands), Container table
External dimensions（W×D×H mm）: 760×420×1350mm
Power Source: AC220V 17A
Weight: 110kg
