Power Supply: AC220V±10%，(50/60)Hz，150W
Working Environment:
Temperature: 10~35℃
Humidity: ≤85％
Measuring range: 250～5600kPa
Indication error: ±0.5% (Range 5%～100%)
Resolution : 1kPa
Refueling speed: 170±15 ml/min
Air pressure adjustment: 0.4 MPa
Hydraulic system tightness: Upper limit of measurement，1min Pressure drop＜10％Pmax
Upper clamp ring aperture: 31.5±0.05 mm
Lower clamp ring aperture: 31.5±0.05 mm
Print: Built-in thermal printer
Communication Interface: RS232(Default) (USB, WIFI optional)
Dimension: 470×315×520 mm
Net Weight: 56kg around
