Power Supply/Motor: AC220V±10% 50Hz 1kW /AC servo motor (Panasonic)
Working Environment:
Temperature: 10~35℃
Humidity: ≤85％
Display: 7 inch color touch screen
Measuring range: (0～20)kN
Resolution: 1N
Indication accuracy: ±1% (Range 5%～100%)
Measured Area: 600×600mm/800×800mm/1000×1000mm/1200×1200mm customizable
Work Capacity: 600mm/800mm/1000mm/1200mm/1500mm customizable
Press Speed: 10mm/min (1～99)mm/min(Arbitrary adjustment)
Parallelism Between Plates: ＜2:1000 （Example: pressure plate 1000×1000mm, ＜2mm）
Return Speed: 1～250）mm/min
Print: Built-in thermal printer
Communication Interface: RS232(Default) (USB, WIFI optional)
