Max. Scale Value: 30/75/15/300/750V; 0.15/0.3/0.75/1.5/3/7.5/15/30A
Approximate Internal Resistance and Consumed Power:Current measurement range 7.5 A or less 0.7 VA. Each voltage measurement range 4.5 VA
Operating Principle: Moving iron type
Class: JIS C 1102 : 1997 Class 0.5
Operating Position: Horizontal
Scale Length: Approximately 135 mm (Deflection Angle: 85°)
Operating Frequency Range: 45 ~ 65 Hz
Linemax: 250V
Scale Divisions 150 divisions
Operating Temperature Range: 0 ~ 40°C
Operating Humidity Range: 30 ~ 75% RH
Storage Temperature Range: -10 ~ 50°C
Storage Humidity Range: 25 ~ 80% RH
Dimension: 260 x 180 x 115 mm
Weight: 4.2 kg
