Performance Parameter
Gas: Measuring range | Resolution | Repeatability | Linearity | Response time | Drift
NH3: 0-100mg/m3 | 0.1ppm | ≤1%FS | ≤1%FS | ≤15S | ≤±1%FS
HCL: 0-100/300mg/m3 | 1mg/m3 | ≤1%FS | ≤1%FS | ≤15S | ≤±1%FS
HF: 0-100/300mg/m3 | 1mg/m3 | ≤1%FS | ≤1%FS | ≤15S | ≤±1%FS
Functional Parameters
Preheat : 30min
Power Supply: AC220V/3KW
Digital output: RS232/485
Analog output : 4-20mA maximum load 900 Ω
Environmental Parameters
Measuring Optical path: 0.5-0.9m
Sampling flow: ≤3L/min
Sample gas temperature: ≤ 300 ℃
Ambient temperature : -20~50℃
Sample gas pressure: Atmosphericpressure ±5kPa
Sampling method: Extraction Type
Size: 330（W）×1150（L）×1560（H）mm
Weight: 120kg
