PON module
Wavelength: 1310nm Upstream / 1490nm Downstream / 1550 Downstream
Pass Zone:1260~1360nm / 1470~1505nm/ 1535~1570nm
Measurement Range: -35~+10dBm / -40~+12dBm / -40~+25dBm
Isolation @1310nm: - / >40dB / >40dB
Isolation @1490nm: >40dB / - / >40dB
Isolation @1550nm: >40dB / >40dB / -
Uncertainty: <±0.5dB
Polarization Dependent Loss: <±0.25dB
Linearity: ±0.1dB
Through Insertion Loss: <1.5dB
Resolution: 15dBm
Connector: SC/UPC
Visual Fault Locator
Wavelength: 650±20nm
Power: 10mW
Mode: CW/1Hz/2Hz
Connector: 2.5mm universal connector
RJ45 Cable Length
Test Distance: 300m
General Information
Display: 3.5 inch TFT LCD display, high resolution 320*480
Data Interface: Micro USB
Power Supply: Lithium battery 3.7V 4000mAh, power adapter 5V DC, 2A
Battery Working Time: >12h
Weight: 350g
