Maxinmum working pressure: 7.5 / 8.5 / 10.5 / 13 bar(g) ( equivalent to109 / 123 / 152 / 189 psig)
Capacity(FAD)*:
50Hz: 28.63 / 28.49 / 23.27 / 20.14 m³/min ( equivalent to 1011 / 1006 / 821 / 711 cfm)
60Hz: 27.91 / 27.77 / 23.74 / 18.53 m³/min ( equivalent to 986 / 981 / 839 / 655 cfm)
Installed motor power: 160 kW; 215 hp
driving mode & Cooling method: Direct Driven; Air Cooling
Noise level ** (dBA): 75
Dimensions(mm) LxWxH: 3110x1890x2150
Weight (kg): 3900
Air outlet pipe diamete: DN80
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
***) EEI 2- Energy Effiency Index 2, which refers to normal energy saving series
Specifications are subject to change without notice.
