Maxinmum working pressure: 7.5 / 8.5 / 10.5 / 13 bar(g) ( equivalent to 109 / 123 / 152 / 189 psig )
Capacity(FAD)*:
50Hz (Min-Max): 14.46-24.1 / 14.4-24 / 12.3-20.51 / 9.97-16.61 m³/min ( equivalent to 511-851 / 508-847 / 434-724 / 352-587 cfm )
60Hz (Min-Max) : 14.62-24.37 / 14.54-24.23 / 11.37-18.95 / 10.09-16.82 m³/min ( equivalent to 517-861 / 514-856 / 401-669 / 356-594 m³/min )
Installed motor power: 132kW; 175 hp
driving mode & Cooling method: Direct Driven; Air Cooling
Noise level ** (dBA): 75
Dimensions(mm) LxWxH: 2435x1795x1715
Weight (kg): 2415
Air outlet pipe diamete: DN80
*) FAD in accordance with ISO 1217 : 2009, Annex C: Absolute intake pressure 1 bar (a), cooling and air intake temperature 20°C
**) Noise level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance: ± 3 dB(A) change without notice.
***) EEI 2- Energy Effiency Index 2, which refers to normal energy saving series
Specifications are subject to change without notice.
