Pressure Type: Differential
Pressure Port Size: 1/8" NPT Female
Pressure Range: 0 to 500 Pa
Accuracy Class: > 0.25%
Dial Size: 5"
Alarm Types (DC/AC): SPDT
GAGE SPECIFICATIONS
Service: Air and non-combustible, compatible gases.
Wetted Materials: Consult factory.
Accuracy: ±2% of FS (3000-0 ±3% of FS). (3000-00 ±4% of FS).
Pressure Limit: -20˝ Hg to 35 psig (-0.677 bar to 1.72 bar). MP option: 35 psig (2.41 bar), HP option: 80 psig (5.52 bar).
Temperature Limits: 20 to 120°F (-6.67 to 48.9°C).
Process Connections: 1/8˝ female NPT (duplicated side and back).
Size: 4˝ (101.6 mm) dial face, 5˝ (127 mm) OD x 3-1/8˝ (79.38 mm); -SS Bezel: 4-3/4˝ (120.7 mm) OD x 2-21/32˝ (67.5 mm).
Weight: 1.8 lb (816 g).
Switch Type: Each set point has 1 form C relays (SPDT).
Relay Contacts: (Resistive load) 1 form C rated 1.0 A @ 30 VDC, 0.3 A @ 110 VDC or 0.5 A @ 125 VAC. Gold over clad silver – suitable for dry circuits.
Electrical Connections: 18˝ (46 cm) cable assembly with 8 conductors. Optional lengths: to 100’ (30.5 m).
Power Requirements: 24 VDC, regulated 10%.
Mounting Orientation: Diaphragm in vertical position. Consult factory for other position orientations.
Set Point Adjustment: Adjustable knobs on face.
Compliance: CE.
